| Camera |
| Image Sensor: |
1/1.9" progressive scan CMOS |
| Effective Pixels: |
1920(H)x1080(V) |
| Signal System: |
PAL/NTSC |
| Minimum Illumination: |
Color: 0.002 Lux @(F1.5, AGC ON) B/W: 0.0002 Lux @(F1.5, AGC ON) |
| White Balance: |
Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| AGC: |
Auto/Manual |
| BLC: |
ON/OFF |
| HLC: |
Support |
| Smart defog: |
Support |
| WDR: |
120dB |
| Shutter Time: |
50Hz: 1/1-1/30,000s 60Hz: 1/1-1/30,000s |
| Day& Night: |
ICR |
| Digital Zoom: |
16X |
| Privacy Masking: |
24 privacy masks programmable; optional multiple colors and mosaics |
| Auto Focus: |
Auto / Semi-automatic / Manual |
| Lens |
| Focal Length: |
5.7 mm to 142.5 mm, 25× Optical |
| Zoom Speed: |
Approx.3.7s(Optical Wide-Tele) |
| Angle of View: |
Horizontal field of view: 59.8° to 2.8° (wide-tele) Vertical field of view: 33.6° to 1.6° (wide-tele) Diagonal field of view: 68.6° to 3.2° (wide-tele) |
| Minimum Working Distance: |
10-1500mm(Wide-Tele) |
| Aperture Range: |
F1.6-F3.4 |
| Pan & Tilt |
| Pan Range: |
360°endless |
| Pan Speed: |
Pan Manual Speed: 0.1° -300°/s, Pan Preset Speed: 540°/s |
| Tilt Range: |
-5°~90° (Auto Flip ) |
| Tilt Speed: |
Pan Manual Speed: 0.1° -240°/s, Pan Preset Speed: 400°/s |
| Proportional Zoom: |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
300 |
| Patrol: |
8 patrols, up to 32 presets per patrol |
| Pattern: |
4 patterns, with the recording time not less than 10 minutes per pattern |
| Power-off Memory: |
Support |
| Park Action: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display: |
ON/OFF |
| Smart-tracking: |
Manual/ Panorama/ Intrusion trigger/ Line crossing trigger / Region entrance trigger / Region exiting trigger |
| Alarm |
| Alarm Input: |
7 Inputs |
| Alarm Output: |
2 |
| Alarm Actions: |
Preset, patrol, pattern, SD/SDHC card recording, relay output, notifi cation on client |
| Input & Output |
| Monitor Output: |
1.0Vp-p / 75Ω, NTSC (or PAL) composite, BNC |
| Audio Input: |
Audio input (LINE input), 2-2.4Vp-p; output impedance: 1KΩ, ±10% |
| Audio Output: |
Line level, impendance: 600Ω |
| Network |
| Ethernet: |
10Base -T, /100Base-TX, RJ45 Connector |
| Max.Image Resolution: |
1920×1080 |
| Main Stream: |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720), 50fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720), 60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream: |
50Hz: 25fps(704×576), 25fps (352×288), 25fps (176×144) 60Hz: 30fps(704×480), 30fps (352×240), 30fps (176×120) |
| Video Compression: |
Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPEG |
| ROI encoding: |
Support 24 areas with adjustable levels |
| Audio Compression: |
G.711ulaw/G.711alaw/G.726/MP2L2 |
| No. of Simultaneous Users: |
Up to 20 users |
| Three-Stream: |
Support |
| Mini SD Card: |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| Security Measures: |
User authentication (ID and PW), Host authentication (MAC address) IP address filtering |
| Client GUI |
| Camera Control: |
Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
| Date & Time Display: |
Time: Week: Date, 6 formats on the Client |
| Client: |
Support iVMS-4200 |
| Web Browser: |
IE 7+, Chrome 18 - 42, Firefox 5.0 +, Safari 5.02 + |
| General |
| RS-485 Protocols: |
HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Menu Language: |
English |
| Power Supply: |
24 VAC & Hi-PoE |
| Power Consumption: |
24 VAC (Max. 60 W) Hi-PoE (Max. 50 W) |
| Working Temperature/Humidity: |
Outdoor: -40°C to 65°C (-40°F to 149°F) |
| Protection Level: |
IP67, IK10, TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Mounting: |
Various mounting modes optional |
| Dimensions: |
Φ 260.3 mm × 326 mm (Φ 10.25" × 12.8") |
| Weight (approx.): |
Approx. 6 kg (13.23 lb) |
| Mount Option: |
Long-arm wall mount: DS-1602ZJ;Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box |
