| Camera |
| Image Sensor: |
|
2× 1/2.8" progressive scan CMOS |
| Effective Pixels: |
|
1920(H)x1080(V) |
| Signal System: |
|
PAL/NTSC |
| Minimum Illumination: |
|
Color: 0.0004 Lux @(F1.5, AGC ON) B/W: 0.0001 Lux @(F1.5, AGC ON) 0 Lux with IR |
| AGC: |
|
Auto/Manual |
| BLC: |
|
ON/OFF |
| HLC: |
|
Support |
| Smart defog: |
|
Support |
| WDR: |
|
120dB |
| Shutter Time: |
|
50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s |
| Day& Night: |
|
ICR |
| Digital Zoom: |
|
16X |
| Privacy Masking: |
|
24 privacy masks programmable |
| Auto Focus: |
|
Auto / Semi-automatic / Manual |
| Lens |
| Focal Length: |
|
4.8 mm to 120 mm, 25× Optical |
| Zoom Speed: |
|
Approx. 4.4 s (optical lens, wide-tele) |
| Angle of View: |
|
Horizontal field of view: 58.2° to 3.2° (wide-tele) Vertical field of view: 32.7° to 1.8° (wide-tele) Diagonal field of view: 66.8° to 3.7° (wide-tele) |
| Minimum Working Distance: |
|
10-1500mm(Wide-Tele) |
| Aperture Range: |
|
F1.5~F3.5 |
| Pan & Tilt |
| Pan Range: |
|
360°endless |
| Pan Speed: |
|
Configurable, from 0.1°/s to 210°/s, Preset Speed: 280°/s |
| Tilt Range: |
|
-20°~90°(Auto Flip) |
| Tilt Speed: |
|
Configurable, from 0.1°/s to 150°/s, Preset Speed: 250°/s |
| Proportional Zoom: |
|
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
|
300 |
| Patrol: |
|
8 patrols, up to 32 presets per patrol |
| Pattern: |
|
4 patterns, with the recording time not less than 10 minutes per pattern |
| Power-off Memory: |
|
Support |
| Park Action: |
|
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display: |
|
ON/OFF |
| Smart-tracking: |
|
Manual Tracking, Auto Tracking (support tracking specified target types such as human and vehicle), Event Tracking |
| Wiper: |
|
Optional |
| Infrared |
| IR irradiation distance: |
|
150m |
| IR irradiation angle: |
|
Adjustable by zoom |
| Alarm |
| Alarm Input: |
|
7 Inputs |
| Alarm Output: |
|
2 |
| Alarm Actions: |
|
Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel |
| Network |
| Ethernet: |
|
10Base -T, /100Base-TX, RJ45 Connector |
| Main Stream: |
|
50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720) 60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720) |
| Sub Stream: |
|
50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240) |
| Third Stream: |
|
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480, 320 × 288) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480, 320 × 240) |
| Video Compression: |
|
Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPEG |
| ROI encoding: |
|
Support |
| Audio Compression: |
|
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| Audio Mode: |
|
OFF/Audio input/Audio output |
| No. of Simultaneous Users: |
|
Up to 20 users |
| Three-Stream: |
|
Support |
| Mini SD Card: |
|
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| Security Measures: |
|
User authentication (ID and PW), Host authentication (MAC address) IP address filtering |
| Client GUI |
| Camera Control: |
|
Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
| Date & Time Display: |
|
Time: Week: Date, 6 formats on the Client |
| Client: |
|
Support iVMS-4200 |
| Web Browser: |
|
IE 7+, Chrome 18 - 42, Firefox 5.0 +, Safari 5.02 + |
| General |
| RS-485 Protocols: |
|
HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power Supply: |
|
24 VAC & Hi-PoE |
| Power Consumption: |
|
Without wiper: 24 VAC, max. 68 W (max. 12 W for heater, and max. 15 W for IR), Hi-PoE, max. 60 W With wiper: 24 VAC max. 70 W (max. 12 W for heater, and max. 15 W for IR), Hi-PoE, max. 60 W |
| Working Temperature/Humidity: |
|
Temperature: -40°C to 70°C (-40°F to 158°F) Humidity: ≤ 90% |
| Protection Level: |
|
IP67 Standard. Lightning protection, surge protection and voltage transient protection meets IEC61000-4-2-2/3/4/5/6 |
| Dimensions: |
|
Φ 266.6 mm × 437 mm (Φ 10.50" × 17.20") |
| Weight (approx.): |
|
8kg (approx.17.64lb) |
