System Parameters
|
|
Processor:
|
High-Performance Embedded SOC Processor
|
|
Operation System:
|
Embedded Linux Operation System
|
|
Video Parameters
|
|
Camera:
|
CMOS Low Illumination 1.3 MP HD Colorful Camera
|
|
Video Compression Standard:
|
H.264
|
|
Resolution:
|
1280 x 720
|
|
Video frame rate:
|
25 fps
|
|
Audio Parameters
|
|
Audio Input:
|
Built-in Omnidirectional Microphone
|
|
Audio Output:
|
Built-in Loudspeaker
|
|
Audio Compression Standard:
|
G.711 U
|
|
Audio Compression Rate:
|
64 Kbps
|
|
Audio Quality:
|
Noise Suppression and Echo Cancellation
|
|
Network Parameters
|
|
Ethernet:
|
10/100 Mbps Self-Adaptive Ethernet
|
|
Network Protocol:
|
TCP/IP, RTSP
|
|
Access Control Parameters
|
|
Internal Card Reader:
|
Built-in IC Card Reader
|
|
Exit button:
|
Exit Button for Opening the Door
|
|
Door Magnetic Detection:
|
Detects Door Magnetic Status
|
|
Light Supplement
|
|
Light Supplement Mode:
|
IR Supplement
|
|
Alarm Parameters
|
|
Alarm Input:
|
Door Magnetic Alarm, Tampering Alarm
|
|
Device Interfaces
|
|
Network Interface:
|
1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
|
|
RS-485:
|
1 RS-485 Half-Duplex Port
|
|
I/O Input:
|
4
|
|
I/O Output:
|
1
|
|
General
|
|
Indoor Station Access Amount:
|
2
|
|
Material:
|
Aluminum Alloy
|
|
Power Supply:
|
12 VDC/24 VDC, Power Over Network Cable (DS-KAD606, DS-KAD612)
|
|
Power Consumption:
|
≤12 W
|
|
Working Temperature:
|
-40° C to +70° C (-40° F to 158° F)
|
|
Working Humidity:
|
10% to 90%
|
|
IP Protection Level:
|
IP65
|
|
Dimensions(L × W × H):
|
182 mm × 100 mm × 33 mm (7.17' × 3.94' × 1.30')
|
|
Certification:
|
FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
|
