| System Parameters |
| Processor: |
High-Performance Embedded SOC Processor |
| Operation System: |
Embedded Linux Operation System |
| Display Parameters |
| Display Screen: |
3.5-Inch Colorful TFT LCD |
| Display Resolution: |
480 × 320 |
| Operation Method: |
Capacitive Touch Keypad |
| Operation interface: |
LCD Display, Easy Menu |
| Video Parameters |
| Camera: |
CMOS Low Illumination 1.3 MP HD Colorful Camera |
| Video Compression Standard: |
H.264 |
| Resolution: |
1280 x 720 |
| Video frame rate: |
PAL: 25 fps, NTSC: 30 fps |
| Audio Parameters |
| Audio Input: |
Built-in Omnidirectional Microphone |
| Audio Output: |
Built-in Loudspeaker |
| Audio Compression Standard: |
G.711 U |
| Audio Compression Rate: |
64 Kbps |
| Audio Quality: |
Noise Suppression and Echo Cancellation |
| Network Parameters |
| Ethernet: |
10/100/1000 Mbps Self-Adaptive Ethernet |
| Network Protocol: |
TCP/IP, RTSP |
| Access Control Parameters |
| Internal Card Reader: |
Built-in IC Card Reader |
| External Card Reader: |
Wiegand 26, Wiegand 34, or RS-485 IC Reader |
| Door Magnetic Detection: |
Detects Door Magnetic Status |
| IR Human Detection |
| Approaching Detection: |
Supporting IR Detection, Vertical Distance: from 60 cm to 80 cm |
| Light Supplement |
| Light Supplement Mode: |
Visible Light Supplement |
| Alarm Parameters |
| Alarm Input: |
Door Magnetic Alarm, Tampering Alarm |
| Device Interfaces |
| Network Interface: |
1 RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
| RS-485: |
1 RS-485 Half-Duplex Port |
| I/O Input: |
8 |
| I/O Output: |
4 |
| Wiegand: |
1 Wiegand Port for Accessing Wiegand IC Card Reader |
| USB : |
1 USB 2.0, Supporting U-Disk |
| General |
| Material: |
Plastic |
| Power Supply: |
12 VDC |
| Power Consumption: |
≤15 W |
| Certification: |
FCC, IC, CE, C-TICK, ROHS, REACH, WEEE |
| Working Temperature: |
-40° C to +60° C (-40° F to 140° F) |
| Working Humidity: |
10% to 90% |
| IP Protection Level: |
IP65 |
| Dimensions(L × W × H): |
418 mm × 145 mm × 61 mm (16.5" × 5.7" × 2.4") |
