| Camera |
| Slow Shutter: |
|
Max. 16 times |
| WDR (Wide Dynamic Range): |
|
> 120 dB |
| Angle Adjustment: |
|
Pan: 0°to 360°, Tilt: 0°to 180°, Rotate: 0°to 360° |
| Image Sensor: |
|
2.0 megapixel progressive scan CMOS |
| Signal System: |
|
PAL/NTSC |
| Min. Illumination: |
|
Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time: |
|
PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Lens: |
|
2.8 mm, 3.6 mm fixed focal lens |
| Lens Mount: |
|
M12 |
| Day& Night: |
|
IR cut filter |
| Horizontal Resolution: |
|
1920 (H) × 1080 (V) |
| Synchronization: |
|
Internal Synchronization |
| Lens |
| Horizontal Field of View: |
|
103.5°(2.8 mm), 82.6°(3.6 mm) |
| Menu |
| 3D DNR (Digital Noise Reduction): |
|
Level 1 to 10 |
| Backlight Compensation: |
|
WDR/BLC/OFF |
| White Light: |
|
Alarm/Lighting/Off |
| D/N Mode: |
|
Auto/Color/BW (Black and White) |
| Auto White Balance: |
|
ATW/MANUAL |
| Private Mask: |
|
ON/OFF, 4 programmable privacy masks |
| Motion Detection: |
|
4 programmable motion areas |
| AGC: |
|
Yes |
| Language: |
|
English/Chinese |
| Function: |
|
Brightness, Sharpness, Mirror, Smart IR |
| Interface |
| Video Out: |
|
1 HD analog output |
| General |
| Visual Alarm: |
|
Yes |
| PIR Range: |
|
Angle: 110°, Range:11 m |
| Material: |
|
Front cover: Metal Main body: Plastic Bracket: Metal |
| Ingress Protection: |
|
IP67 |
| Operating Conditions: |
|
-40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: |
|
12 VDC±25% |
| IR Range: |
|
Up to 20m |
| Communication : |
|
Up the coax Protocol: Pelco-C(CVBS output), HIKVISION-C(TVI output) |
| Dimension: |
|
88.6 mm × 81.3 mm × 224.7 mm (3.49" × 3.20" × 8.85" ) |
| Weight: |
|
Approx. 430 g (0.95 lb.) |
